Stumpjumper 15 Alloy - FOX Coil
Size Guide
Stumpjumper 15 Alloy - FOX Coil
Stumpjumper 15 Alloy - FOX Coil
Size Guide
Product Details
Description
Frameset
Frame
M5 Alloy chassis and rear-end, Trail Geometry, SWAT™ Door integration, head tube angle adjustment, threaded BB, internal cable routing, 12x148mm dropouts, sealed cartridge bearing pivots, SRAM UDH compatible, 145mm of travel
Seat Binder
Alloy, 38.6mm
SWAT
SWAT internal downtube storage
Suspension
Rear Shock
FOX DHX Factory, Ride Dynamics Trail Tune, 210x55mm, S2: 400lbs, S3: 450lbs, S4: 500bs, S5: 550lbs, S6: 600lbs
Fork
FOX FLOAT 38 Factory, GRIP X2 damper, HS and LS rebound and compression adjustment, 15x110mm QR axle, 44mm offset, 160mm of travel
Cockpit
Seat Post
PNW Loam OE Dropper, tool-less travel adjust, Range lever, 34.9, S2: 150mm, S3: 170mm, S4-S6: 200mm
Saddle
Bridge Comp, Hollow Cr-mo rails, S1-S2: 155mm, S3-S6: 143mm
Stem
Deity, 35mm clamp, 35mm length
Grips
Deity, Knuckleduster, Black
Handlebars
Deity, Racepoint, 5-degree upsweep, 9-degree backsweep, 810 width, S2: 25mm rise: S3-S6: 38mm rise
Brakes
Front Brake
TRP DH-R EVO, 4-piston caliper, hydraulic disc, 220mm
Rear Brake
TRP DH-R EVO, 4-piston caliper, hydraulic disc, 203mm
Drivetrail
Shift Levers
Shimano SLX, M7100, 12spd
Rear Derailleur
Shimano SLX, M7100, SGS, 12-speed
Cassette
Shimano SLX, CS-M7100, 12-speed, 10-51t
Shift Levers
Shimano SLX, M7100, 12spd
Crankset
Shimano SLX, M7120, 32T ring, 55mm chainline, S2-S3:165mm, S4-S6: 170mm
Chain
Shimano SLX, M7100, 12-speed
Bottom Bracket
Shimano, BB-MT801, Threaded
Wheels & Tyres
Front Hub
DT Swiss 370, 15x110mm, 28h
Rear hub
DT Swiss 370, 12x148mm, 32h
Rims
Roval Traverse, hookless alloy, 30mm inner width, tubeless ready, Front: 29, Rear: 27.5
Butcher, GRID TRAIL casing, GRIPTON® T9 compound, 2Bliss Ready, 29x2.3"
Butcher, GRID TRAIL casing, GRIPTON® T9 compound, 2Bliss Ready, 29x2.3"
Eliminator, GRID GRAVITY casing, GRIPTON® T9/T7 compound, 2Bliss Ready, 27.5x2.3"
Eliminator, GRID GRAVITY casing, GRIPTON® T9/T7 compound, 2Bliss Ready, 27.5x2.3"
Spokes
Sapim Force
Tubes
Standard, Presta valve
Accessories
